Key Features
- Vibration Suppression – Up to 8× anti-vibration performance for smoother cutting.
- High Rigidity & Stability – Quenched and hardened for enhanced structural integrity.
- Reduced Tool Breakage – Minimal clearance during machining reduces cutting edge damage.
- Enhanced Work Efficiency – Stable cutting allows for higher productivity.
- Multiple Sizes & Specifications – Compatible with a wide range of inserts and machines.
Available Specifications
- C12M-SCLCR06, C06K-STUBR06, C12M-SCLCR09
- C07K-STUBR06, C10K-SDUCR07, C08K-STUBR06
- C12M-SDUCR07, C08K-STUCR09, C10K-SVJCR111
- C10K-STUCR11, C12M-SVJCR11, C12M-STUCR11
- C05H-SWUBR06, C08K-STUPR08, C06K-SWUBR06
- C08K-STUPR09, C07K-SWUBR06, C10K-STUPR09
- C08K-SWUBR06, C10K-STUPR11
- And more models available upon request.
Material Options – Performance & Cost Comparison
- HSS Toolholder
- Strengths: High toughness, not easy to break, 4× vibration resistance.
- Cost: High cost-effectiveness, ideal for general machining.
- Tungsten Carbide Anti-Vibration Toolholder
- Strengths: Premium tungsten carbide for deep hole machining, 8× anti-vibration performance, long lifespan.
- Cost: Most expensive option, but best for demanding applications.
- Carbon Steel Toolholder
- Strengths: Budget-friendly, suitable for light-duty machining.
- Cost: Lowest price due to inexpensive raw materials.
Tip: Choose your toolholder material based on your application needs and budget.
Applications
- Deep hole boring and turning
- Internal machining for automotive and aerospace parts
- High-precision CNC applications where vibration control is critical
- Machining of hardened steels, alloys, and other difficult materials
Why Choose Our Anti-Vibration Toolholders
- Advanced heat treatment for durability
- Wide model range for multiple machine setups
- Strict quality control for consistent performance
- Expert support for material and size selection
